ORCA Closed Loop Refrigerated Recirculating Circulator | Advanced Refrigerated Circulator

Shipping calculated at checkout.

A new sustainability focused, energy‑efficient recirculating chiller designed to replace tap‑water‑based cooling in laboratories.

Model:

Product variants:

Perfectly designed to replace tap water-based cooling solutions in labs and slash utility spend
Energy efficient, adaptive cooling – cooling power adapts to varying heat load conditions across a range of -10 to 40°C
Easy to use and intuitive interface. No training required
System exhausts less heat to the room, reducing demand on HVAC
Effective cooling control with excellent stability of ±0.1°C
Easy integration - compact design with a range of accessory connectors and hosing kits
Peace of mind - 3-year warranty and high quality, manufactured in the UK
Very quiet 49dB operation
New modern, eye-catching design to stand out in labs
UK designed and manufactured to the highest specifications

Specification	Unit	Value
Dimensions	cm (wdh)	260 x 450 x 400
Capacity	L	1.7
Temperature Range	°C	-10 to 40
Stability	±°C	0.1
Setting Resolution	°C	0.1
Cooling Power @20°C	W	300
Cooling Power @10°C	W	180
Cooling Power @0°C	W	80
Flow Rate (max)	L/min	15
Pump Pressure (max)	mbar	450
Pump Connection		2x Female ½” BSP fittings
Min/Max Fluid Levels	mm	120/130
Timer	min	1-999 with audible alarm
Safety		High temperature warning alarm
Level Protection		Low level float protection
Weight	kg	20
Noise	dB	49
Electrical Supply	V, Hz	230, 50-60 or 120, 60
Regional Options		UK, EU & US cord sets
Warranty	years	3

Ideal for reaction chemistry, condensers, reflux, solvent extraction and Soxhlet systems
Replaces high‑cost tap‑water cooling with closed‑loop
precision for better accuracy and reproducibility
Cooling for analytical instruments, biological workflows, optics and general temperature control
Temperature control of bioreactors and fermentation vessels
Great for facilities aiming to cut water use and meet sustainability standards such as LEAF
